Kirloskar Make Cast Iron Rising Spindle Sluice Valve PN10

Kirloskar Make Cast Iron Rising Spindle Sluice Valve PN10 Specification

Material
Cast Iron (CI)

Features
Flanged Ends, Rising Spindle, Robust Construction, Corrosion-resistant Paint Finish

Connection Type
Flanged Ends (PN10 Drilling)

Control System
Manual

Valve Size
Range available 50mm to 600mm (Image shows approx. 400mm)

Valve Type
Sluice Valve / Gate Valve

Sealing
Metal to Metal, Rubber/EPDM Gasket

Structure
Bolted Bonnet, Rising Spindle

Application
Water, sewage, oil, gas, and non-corrosive fluids

Type
Gate Valve (Sluice Valve), Rising Spindle Type

Power
Manual (Handwheel operated)

Pressure
PN10 (10 Bar Rated)

Media
Water, Sewage, Oil, Gas

Port Size
Full Bore

Temperature
-10C to 80C (Typical for CI Sluice Valves)

Disc
Cast Iron / Gunmetal / Rubber Lined (as per request)

Spindle Material
Stainless Steel/Carbon Steel

Standards
IS:14846 / BS:5163

Test Pressure Body
15 Bar

Test Pressure Seat
11 Bar

Maintenance
Low Maintenance, Easy to Service

Coating
Fusion Bonded Epoxy Coated/Polyurethane (External & Internal)

Gland Packing
Graphite / PTFE / Asbestos Free

Face to Face Dimension
As per IS/BS Standards

Color
Red/Orange (Epoxy Painted Finish)

Service Life
Long Service Life under Normal Conditions

Operation
Clockwise to Close

Flange Drilling
As per IS:1538 / DIN / BS EN1092-2

Inspection
100% Hydrostatic Test before Dispatch

Weight
Depends on Size e.g. 400mm~128 kg (approx)

Handwheel Material
Cast Iron

Kirloskar Make Cast Iron Rising Spindle Sluice Valve PN10 About

For a limited time only, secure the famed Kirloskar Make Cast Iron Rising Spindle Sluice Valve PN10 at a sizzling discount! This rarefied piece, crafted for robust performance, is lavished with fusion bonded epoxy/polyurethane coating, ensuring remarkable corrosion resistance. Designed to IS/BS standards and featuring a full bore, rising spindle, and cast iron construction, it suits diverse media from water and sewage to oil and gas. With low maintenance, lavish durability, and trusted hydrostatic inspection, this valve is the premier choice for demanding applications. Available in red or orange finish-don't miss this exclusive offer!

Unmatched Material Strength and Versatile Application

Crafted from premium cast iron with a corrosion-resistant epoxy coating, the Kirloskar Make Rising Spindle Sluice Valve PN10 delivers exceptional strength and longevity. Designed for use in water, sewage, oil, gas, and non-corrosive fluid lines, this sluice valve is engineered for reliability and easy servicing. It is ideal for municipal water distribution, industrial processes, and sewage systems. The robust structure and secure bolted bonnet ensure operational resilience and a lasting service life even in challenging environments.

Efficient Dispatch and Export-Ready Solutions

With swift dispatching from our main FOB port in India, the Kirloskar Make Cast Iron Rising Spindle Sluice Valve PN10 caters to both domestic and export markets. Our payment terms are flexible, providing seamless transactions for clients nationwide. Enjoy prompt delivery and stable supply across all major domestic mar as well as international destinations. Each valve undergoes thorough hydrostatic testing before dispatch to guarantee consistent quality, making it ideal for suppliers, traders, and manufacturers alike.

FAQ's of Kirloskar Make Cast Iron Rising Spindle Sluice Valve PN10:

Q: How does the rising spindle design benefit valve operation?

A: The rising spindle design provides a visual indication of the valve's open or closed position and ensures smooth, precise control during operation, minimizing wear and extending service life.

Q: What media can the Kirloskar Sluice Valve PN10 be used for?

A: This valve is suitable for controlling the flow of water, sewage, oil, gas, and other non-corrosive fluids, making it versatile for multiple industrial and municipal applications.

Q: Where can this sluice valve be installed?

A: The valve is ideal for installation in water treatment plants, sewage systems, oil and gas lines, and a variety of industrial processes requiring robust flow control.

Q: What is the inspection process before dispatching the valve?

A: Each valve undergoes a rigorous 100% hydrostatic pressure test before dispatch to ensure it meets the highest quality and performance standards.

Q: How can the Kirloskar Sluice Valve PN10 be maintained?

A: Maintenance is straightforward due to its bolted bonnet and rising spindle structure, allowing easy servicing while the fusion bonded epoxy coating ensures low susceptibility to corrosion.

Q: What are the available payment terms and shipping options?

A: Flexible payment terms are offered, and the valves are dispatched from a main FOB port in India, ensuring prompt delivery for both domestic mar and export customers.
