DN150 Forbes Marshall Cast Steel Piston valve Class 300 PSVAL

DN150 Forbes Marshall Cast Steel Piston valve Class 300 PSVAL Specification

Connection Type
Flanged End

Material
Cast Steel A216 Gr.WCB

Usage
steam, superheated steam, heat transfer fluid, water and compressed air.

Application
150 mm

Sealing
Class IV

Size
150 mm

Height
76 Centimeter (cm)

Product Type
Cast Steel Piston Valve Class 300

Weight
110 Kilograms (kg)

Port Size
150 mm

Color
Silver

Length
45 Centimeter (cm)

Width
32 Centimeter (cm)

Disc
SS

DN150 Forbes Marshall Cast Steel Piston valve Class 300 PSVAL Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Mumbai Port

Payment Terms
Telegraphic Transfer (T/T)

Supply Ability
50 Pieces Per Day

Delivery Time
1 Days

Sample Available
No

Packaging Details
As per Standard Packing

Main Export Market(s)
Australia, South America, Eastern Europe, Western Europe, Middle East, Asia, Central America, North America, Africa

Main Domestic Market
All India

About DN150 Forbes Marshall Cast Steel Piston valve Class 300 PSVAL

Description

Forbes Marshall Piston Valves, PSVAL, provide perfect tightness and durable stability on different media such as steam, superheated steam, heat transfer fluid, water and compressed air.

Feature:

480 to 600 % higher sealing area.
Class VI bubble tight shut off: burnished piston sealing.
Zero gland leakage, Soft seated Sealing Perfect interface fit, Interchangeable parts
Protection of wetted parts: In open and closed condition, piston remains enclosed in sealing rings and is hence protected from erosive or corrosive material.

Benefit:

Offers Class VI bubble tight shutoff with zero leakage.
Smooth operating eliminates changes of water hammering in the line.
Ease of maintenance as critical components can be replaced without removal of valve from line.
Valve seating on the sides eliminates the possibility of wire drawing effect.
Low cost of operation, maintenance and repairs.
